AVID
Pro Tools | MTRX II
Digital I/O Card

128 Channel IP Audio Dante Card

Add up to 128 channels of high-density, low-latency digital audio using Dante to Pro Tools | MTRX, MTRX II (128 channels at 44.1 kHz or 32 channels at 192 kHz).

The MTRX 128-Channel IP Audio Dante Card lets you add up to 64 bi-directional (128) low-latency channels to the Pro Tools | MTRX base unit. Dante has established itself as the leading format for transmitting audio over a network. Dante is an extremely fast, low-latency, bandwidth-friendly format that allows you to transmit 64 bidirectional channels of 24-bit/48 kHz audio at a standard latency of 1 ms and a transfer rate of only 74 Mbps over a single network connection. With Dante, you can transmit up to 512 24-bit/48 kHz audio channels over a single Gigabit network connection. With Dante, you can add as many audio channels as you want to a network by simply adding more MTRX or other Dante-equipped interfaces. Adding new devices to a Dante network couldn't be easier, as it features automatic device discovery and assigns easily recognisable device names. Dante is extremely cost-effective and can use existing network infrastructure to send and receive audio over CAT5/6 cables in a multi-room setup.

  • Adds Dante audio networking capabilities to the Pro Tools | MTRX base unit.
  • 64 channels at 44.1/48kHz, 32 channels at 88.2/96kHz or 16 channels at 192kHz
  • Standard latency of 1 ms
  • Uses standard Cat5/6 Ethernet cables and connectors
  • Automatic device detection shows newly connected devices in the Dante software

DANTE AUDIO OVER IP

Supported sample rates: 44.1 kHz-192 kHz
Channels: 128 channels at 44.1 kHz, 32 channels at 192 kHz per card; supports up to 1,024 MADI channels with eight cards installed
Connectivity: Dual Ethernet, switched or redundant
Sample rate conversion: Bi-directional

Pro TOOLS | MTRX

128 CHANNEL IP AUDIO DANTE CARD

Pro TOOLS | MTRX

128 CHANNEL IP AUDIO DANTE CARD

MORE PRO TOOLS MTRX

Pro Tools | MTRX Thunderbolt 3 module

Pro Tools | MTRX Thunderbolt 3 module

Pro Tools | MTRX II Digital I/O Card Thunderbolt™ 3 Module Provides 256 channels (MTRX II) or 64 channels (MTRX Studio) of low latency Native thunderbolt conectivity to Pro Tools and other Core Audio DAWs. (256 channels of native low-latency I/O at 44.1/48…
MTRX 8 Pristine DA Card

Pro Tools | MTRX 8 Pristine DA Card

MTRX 8 Pristine DA Card ANALOG I/O CARD Add eight channels of line-level analog outputs with an output level control, to Pro Tools | MTRX, MTRX II, delivering the utmost audio transparency and clarity.
MTRX 2 Mic/Line Pristine AD Card

Pro Tools | MTRX 2 Mic/Line Pristine AD Card

MTRX 2 Mic/Line Pristine AD Card ANALOG I/O CARD Add two channels of analog inputs and mic preamps with relay-based gain circuit - an ideal low-cost option for talkback and tracking to Pro Tools | MTRX, MTRX II.
Pro Tools | MTRX II

Pro Tools | MTRX II

Pro Tools | MTRX II Base Unit with DigiLink, Dante 256, SPQ Pro Tools | MTRX II not only offers 64 DigiLink channels, 256 Dante channels and 64 MADI channels, but is also fully modular. Configure the eight slots with all the analog, digital, and additional…
MTRX 8 Mic/Line Pristine AD Card

Pro Tools | MTRX 8 Mic/Line Pristine AD Card

MTRX 8 Mic/Line Pristine AD Card ANALOG I/O CARD Add eight channels of analog inputs and mic preamps with relay-based gain circuit, providing the utmost transparency and clarity, to Pro Tools | MTRX, MTRX II.
