DPA Microphones
4018

Supercardioid Microphone

HIGHLY-DIRECTIONAL SUPERCARDIOID PATTERN

  • Low noise and high sensitivity
  • Highly directional for high isolation
  • Most controlled supercardioid shape
  • Uniform, frequency independent directionality
  • Modular flexibility
Designed for a broad range of long-distance broadcast, ENG and film miking applications, such as booming, dialogue, interview and table or podium use, the 4018 Supercardioid Microphone offers superb flexibility through modular accessories.

This microphone is part of the flexible pencil Microphones series. It has a highly-directional supercardioid pickup pattern with a smooth and uniform off-axis frequency response. The supercardioid shape is frequency independent, securing an identical sound color around the microphone. The usual rear lobe heard on most supercardioids is minimized on this capsule. This makes it much more isolated without sudden frequency dependent peaks and dips.
DPA 4018

VARIANTS

4018A SUPERCARDIOID MICROPHONE

The 4018A supercardioid microphone is designed for a wide range of applications from music recording and broadcast, electronic reporting and film sound recording. Ideal for booming, dialogue, interview and table or spot recordings.

4018C COMPACT SUPERCARDIOID MICROPHONE

Comparable to the 4018A, but with an even shorter length of only 6.4 cm, the 4018C compact supercardioid microphone has high directivity and a smooth and consistent off-axis frequency response. A very small microphone with a great sound. Ideal as a support or hanging microphone for orchestral recordings.

4018E SUPERCARDIOID MICROPHONE

Ideal for inconspicuous or distant miking, for example suspended or table-mounted, the 4018ER/ES supercardioid microphone is an ultra-compact microphone with a very narrow pick-up pattern. With a length of only 35 mm, the unobtrusive microphone is as unique as its supercardioid characteristic with high directivity and a smooth and uniform off-axis frequency response.


The 4018ER/ES supercardioid microphone combines the MMC4018 supercardioid microphone capsule with the MMP-ER/ES modular active cable, XLR, an integrated cable solution with side (4018ES) or rear (4018ER) output.

It is designed for a wide range of applications from music recording and broadcasting, electronic reporting and film sound applications. Ideal as a support or suspended microphone for orchestral recording when used with the SM4000-C bracket included in the package. This allows the 4018E to be suspended from the ceiling and mounted precisely and reproducibly for support miking of orchestral groups or room sound.
DPA 4018ES

Combine it with the preamp of your choice

At any time, and with no tools needed, it is possible to transform the MMC4018 Supercardioid Microphone Capsule into a new configuration.

The MMP-A Microphone Preamp is an ultra-transparent, transformerless preamp with active drive for impedance balancing. The MMP-C Compact Microphone Preamp is an ultra-compact preamp with active drive for impedance balancing. It has a slightly softer character than the other preamps in the pencil Microphones Series.

Other preamps include the very small form factor types MMP-E Modular Active Cable (XLR output) and MMP-G Modular Active Cable (MicroDot output), allowing for very slim set-ups. The MMP-G even allows you to match a larger microphone directly to a wireless transmitter. The MMP-G, together with the GSM4000 Gooseneck Shock Mount, can be used for anything from very lightweight booming applications to very high-end instrument miking using the 4099 CORE series of instrument mounting options.

DPA 4018

SUPERCARDIOID MICROPHONE

DPA 4018

SUPERCARDIOID MICROPHONE

MORE PENCIL MICROPHONES

4015 Wide Cardioid Mic

DPA 4015 Wide Cardioid Microphone

The 4015 is the perfect fill-in between an omnidirectional and a directional microphone. The off-axis characteristics of this mic are totally linear, a unique quality when it comes to authentic sound reproduction. Any leakage that occurs from off-axis sound…
2011 Twin Diaphragm Mic

DPA 2011 Twin Diaphragm Cardioid Microphone

The 2011 Twin Diaphragm Cardioid Mic is a directional microphone. The distinctive sound of this microphone is well balanced. It bridges the gap between the extreme sound quality of the Recording Microphone Series and the well-known Miniature Microphone…
DPA 4011 Cardioid Mic

DPA 4011 Cardioid Microphone

This condenser microphone is renowned in recording studios and live applications around the world as an exceptional mic. State-of-the-art components have been carefully selected to provide optimal neutrality, accuracy and extremely low distortion. The…
DPA 4017 Shotgun Mic

DPA 4017 Shotgun Microphone

Designed for a broad range of applications, the 4017 Shotgun Mic is ideal for use with camera systems, in fixed positions at sports facilities, for broadcast / ENG / film booming and even studio recording environments. This condenser microphone capsule is…

ACCESSORIES DPA 4018

DUA0020 Foam Windscreen

DUA0020 Foam Windscreen for Pencil Microphone

This windscreen is designed for use with DPA Compact Pencil Microphone Series and DPA Gooseneck Series. It provides excellent protection against wind and pop noises without attenuating the higher frequencies beyond the tolerance field of the microphone's…
