• Due to the use of cellular PP (polypropylene) insulation, a conductor with a larger cross-section is used despite the cable’s compact overall diameter, which naturally results in lower attenuation.
• Easy cable core identification system, such as numbered cable core
• Easy wiring assisted by the same conductor size drain wire
• Flexible and good low temperature characteristic
• Ø 9,0 mm

The very flexible and compact design allows easy cabling, installation and handling of these Multicore 110Ω AES/EBU DIGITAL AUDIO cables.

MOGAMI's 3160 Multicore is optimised for the transmission of digital audio signals according to the AES/EBU standard. The required impedance of 110 ohms is guaranteed with a tolerance of only ±10%. A low capacitive resistance and selected materials guarantee not only the excellent transmission properties but also the uncomplicated handling of the cable.
