The system provides the utmost digital connectivity, offering up to 32×32 ADAT channels at 48 kHz and 64×64 Dante channels with AES67 support. It also supports secure, redundant, or switched network operation. Connectivity can be expanded via two optional MADI-SFP slots. These enable dual MADI streams, redundant connections, and direct cross-routing between MADI, Dante, and ADAT at sample rates of up to 192 kHz.

The 3-inch IPS color display on the front panel provides direct and intuitive control. The display shows level meters, routing, clocking, and device status in real time. A flexible routing matrix is available for signal management, offering both fast 8-channel block routing and precise single-channel routing. Front-panel headphone monitoring allows you to monitor any digital input or output signal directly without affecting the existing routing.

Other practical features include eight internal preset slots, a device lock to prevent accidental changes, and comprehensive remote control via RemoteFish software (Windows/macOS) using USB-C or MIDI Control Change commands.

MADI functionality can be enabled via two MADI SFP slots, an optional MADI license, and compatible Ferrofish MADI SFP modules.

The VERTOpro can be configured directly via the front panel. The high-resolution, 3-inch, IPS color display shows level meters, time, interface status, routing information, and device configuration access.

The internal routing matrix allows signals to be freely routed between Dante, ADAT, and, when the optional MADI function is enabled, MADI. Routing can be performed quickly in blocks of eight channels or individually per channel.

The VERTOpro 32 is equipped with two MADI-SFP slots. MADI functionality can be enabled with an optional MADI license and compatible Ferrofish MADI-SFP modules.

Dante I/O

• 64 × 64 @ 48 kHz
• 32 × 32 @ 96 kHz
• 16 × 16 @ 192 kHz
• 2 × RJ45 Gigabit
• Switched and Redundant modes
• AES67

General

• 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz
• Half 19-inch, 1U enclosure

MADI

• 2 SFP slots
• 64- and 56-channel modes

USB-C

• USB-C MIDI

Headphone

• 6.3 mm jack
• ESS ES9023 DAC
• 4 gain settings

Package Contents

• Device
• PSU
• Manual

MIDI I/O

• 3.5 mm TRS MIDI Type A In / Out
• RemoteFish
• MIDI CC

Power Supply

• 12 V DC / 3 A
• Locking connector
• Internal self-resetting polyfuse

ADAT I/O

• VERTOpro 32: 4 × ADAT IN / 4 × ADAT OUT
• SMUX 1/2/4
• SMUX support up to 192 kHz

Wordclock I/O

• BNC In / Out
• Switchable 75 Ω termination

Environmental

• +5 °C to +45 °C
• <75% RH, non-condensing

Weight/Size

• 220 × 135 × 44 mm
• Weight: 1 kg
